Miele DAH2960 Escala 90cm Wall Extractor Hood

Product Code: DAH2960
GET 5% OFF
Auto-Applied At Checkout!
Miele DAH2960 Escala 90cm Wall Extractor Hood
Miele DAH2960 Escala 90cm Wall Extractor Hood
Miele DAH2960 Escala 90cm Wall Extractor Hood
5% OFF WITH "
TAKE5
"
CLICK TO COPY

£1,649.00

Or 3 payments of £549.67 with
Monthly, Interest Free
Seen it cheaper?
In Stock
2 Year Warranty
Delivery From 3 - 7 Working Days*
Instalment plans available from
£549.67 per month
BUY NOW
Need help? Call us on 01622 541312
Google reviews Link

FREE UK Delivery

On all orders over £300
3 to 7 Working Days*
Express/Nominated Day Delivery Options Available on Selected Stock*
*Available delivery dates depend on postcode & stock availability.

Additional Services**

Installation from £40
Packaging Recycling from £5
Appliance Removal from £25
**Installation & Recycling services are available but depend on postcode.
recirculation-or-duct-out
Extraction Type
65 DB
Noise Rating
Energy Rating
yes
Smart Appliance
Overview
Specification
Detail

Miele
 DAH2960

  • Obsidian Black Finish Miele Extractor Hood – 3+1 Intensive Speed, 675m3/h Max Capacity, Duct Out or Recirculation (sold separately), Touch control operation & Noise Rating of just 65dB(A) with Energy Rating B.
  • Stainless Steel (10-ply) Grease Filter – Can be cleaned in Dishwasher.
  • Miele CleanCover – Easy cleaning & Protects electrical components + motor.
  • Miele@Home – Make your life smart; connect up all your Miele appliances using your smart devices with Con@ctivity.

Miele
 Model DAH2960 Key Features

SPECIFICATION

CONSTRUCTION TYPE

Wall mounted cooker hood

OPERATING MODES

Type of air guideConvertible
Active charcoal filter (order separately)DKF 29

DESIGN

ColourObsidian black
Edge extraction

USER CONVENIENCE

Miele@home
Automatic function Con@ctivity
Electronic controls
Touch controls
Power levels (number without Booster level)3

EFFICIENCY AND SUSTAINABILITY

Energy efficiency class (A+++ to D)B
Annual energy consumption in kWh/year72.30
Fluid dynamic efficiency classB
Lighting efficiency classA
Grease filtering efficiency classD

CLEANING AND CARE

Easy-to-clean canopy interior – CleanCover

FILTER SYSTEM

Number of dishwasher-safe stainless steel grease filters (10-ply)2

LIGHTING

LED
Number x W1 x 3,2 W
Light intensity in Lx300 lx
Colour temperature in K3500 Kelvin

FAN

Dual-action blower
DC motor

EXHAUST AIR

Air throughput in Level 1 (m³/h) according to EN 61591215
Air throughput in Level 2 (m³/h) according to EN 61591315
Air throughput in Level 3 (m³/h) according to EN 61591415
Air throughput in booster level 1 (m³/h)675
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-341
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-347
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-353
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-365
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1327
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1333
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1339
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1351

RECIRCULATION

Air throughput in Level 1 (m³/h) according to EN 61591190
Air throughput in Level 2 (m³/h) according to EN 61591280
Air throughput in Level 3 (m³/h) according to EN 61591380
Air throughput in Booster level 1 (m³/h) according to EN 61591575
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-347
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-354
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-360
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-371
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1333
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1340
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1346
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1357

SAFETY

Safety shut-off
Single-ply safety glass (ESG)

TECHNICAL DATA

Overall height for vented and external in in. (mm)
830
Overall height for extraction mode and external mode cooker hoods in mm
1210
Overall height for recirculation in in. (mm)
443
Overall height for recirculation mode cooker hoods in mm
443
Canopy width in in. (mm)
898
Canopy height in in. (mm)
443
Depth of hood canopy in in. (mm)
388
Minimum height above electric hobs in mm
450
Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm
650
Net weight in kg
18
Length of supply lead in m
1.30
Standard plug fitted
Total rated load in kW
0.20
Voltage in V
230
Fuse rating in A
10
Frequency in Hz
50
Number of phases
1

INSTALLATION NOTES

Extraction ducting connection at top
Extraction connection at top and rear
Diameter of extraction ducting connection in mm150

ACCESSORIES INCLUDED

Non-return flap

EAN

4002516801504

Discover the Miele DAH2960 Escala 90cm Wall Extractor Hood in Obsidian Black on KDH Electrical. Obsidian Black Finish Miele Extractor Hood – 3+1 Intensive Speed, 675m3/h Max Capacity, Duct Out or Recirculation (sold separately), Touch control operation & Noise Rating of just 65dB(A) with Energy Rating B. Stainless Steel (10-ply) Grease Filter – Can be cleaned in Dishwasher. Powerful – 675 m3/h on booster setting. Energy Efficient – LED Lighting. Miele CleanCover – Easy cleaning & Protects electrical components + motor. Miele@Home – Make your life smart; connect up all your Miele appliances using your smart devices with Con@ctivity.



Edge Extraction – In cooker hoods with edge extraction panels, the commercial-looking metal grease filters are hidden behind a decorative cover. The cooking vapours are drawn in at the outer edges.
Stainless steel grease filters (10-layer) – Miele cooker hoods are equipped with 10-ply stainless-steel grease filter(s) for excellent grease removal. Built-in fall protection allows you to handle them safely and protects your hob from damage. The top layer and filter frame are made of high-quality stainless steel so that no visible discolouration occurs from being cleaned in the dishwasher and they retain their stunning appearance.
Miele CleanCover – Located behind the grease filters is the Miele CleanCover: Instead of sharp metal edges and electrical components you will find only a sealed, smooth surface. It is particularly easy to clean and protects you from coming in contact with cables and motor components. Miele attention to detail – for your convenience and safety.





Additional information

DimensionsH: 83 x W: 89.8 x D: 38.8
Brand

Miele

Colour

Black

Energy Rating

B

Extraction Type

Recirculation or Duct Out

Noise Level (dB)

65

Programmes

4

Smart Appliance

Yes

SKUDAH2960
GTIN4002516801504
