Miele DA2808 90cm Built In Extractor Hood

Product Code: DA2808
GET 5% OFF
Auto-Applied At Checkout!
5% OFF WITH "
TAKE5
"
CLICK TO COPY
POA
Or 3 payments of £0 with
Monthly, Interest Free
2 Year Warranty
Instalment plans available from
£0 per month
Specialist Item
Please contact us for availability.
01622 541 312
Out Of Stock Enquiry form.
Need help? Call us on 01622 541312
Google reviews Link

FREE UK Delivery

On all orders over £300
3 to 7 Working Days*
Express/Nominated Day Delivery Options Available on Selected Stock*
*Available delivery dates depend on postcode & stock availability.

Additional Services**

Installation from £40
Packaging Recycling from £5
Appliance Removal from £25
**Installation & Recycling services are available but depend on postcode.
Overview
Specification
Detail

Miele
 DA2808

  • Brilliant White Finish Miele Ceiling Extractor Hood – Duct Out or Recirculation (sold separately), Remote control operation (not included), Run-On function, Filter Indicator & Noise Rating of just 57dB(A) with Energy Rating A+.
  • Stainless Steel (10-ply) Grease Filter – Can be cleaned in Dishwasher.
  • Powerful – 725 m3/h on booster setting.

Miele
Model DA2808 Key Features

SPECIFICATION

CONSTRUCTION TYPE

Ceiling extractor

OPERATING MODES

Type of air guideCan be retrofitted
Recirculation conversion kit (order separately)DUU 2900
Active charcoal filter (order separately)DKF 20-P

DESIGN

ColourBrilliant white
Edge extraction

USER CONVENIENCE

Miele@home
Automatic function Con@ctivity
Electronic controls
Miele@mobile app
Power levels (number without Booster level)3
Programmable Booster level switch-off
Run-on time 5/15 min.
Grease filter saturation indicator
Grease filter saturation indicator programmable
Active charcoal filter saturation indicator programmable

EFFICIENCY AND SUSTAINABILITY

Energy efficiency class (A+++ to D)A+
Annual energy consumption in kWh/year27.60
Fluid dynamic efficiency classA
Lighting efficiency classA
Grease filtering efficiency classB
PowerManagement system
ECO motor

CLEANING AND CARE

Easy-to-clean canopy interior – CleanCover

FILTER SYSTEM

Number of dishwasher-safe stainless steel grease filters (10-ply)2

LIGHTING

LED
Number x W4 x 3 W
Light intensity in Lx720 lx
Colour temperature in K3500 Kelvin
Dimmer function

FAN

Dual-action blower
DC motor

EXHAUST AIR

Air throughput in Level 1 (m³/h) according to EN 61591200
Air throughput in Level 2 (m³/h) according to EN 61591310
Air throughput in Level 3 (m³/h) according to EN 61591450
Air throughput in booster level 1 (m³/h)725
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-335
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-344
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-353
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-365
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1320
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1330
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1338
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1350

RECIRCULATION

Air throughput in Level 1 (m³/h) according to EN 61591115
Air throughput in Level 2 (m³/h) according to EN 61591215
Air throughput in Level 3 (m³/h) according to EN 61591335
Air throughput in Booster level 1 (m³/h) according to EN 61591535
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-343
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-353
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-362
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-372
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1328
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1339
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1347
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1357

SAFETY

Safety shut-off

TECHNICAL DATA

339
339
Overall height for vented and external in in. (mm)339
Overall height for extraction mode and external mode cooker hoods in mm339
Overall height for recirculation in in. (mm)339
Overall height for recirculation mode cooker hoods in mm339
Canopy width in in. (mm)880
Canopy height in in. (mm)342
Depth of hood canopy in in. (mm)500
Minimum height above electric hobs in mm450
Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm650
Net weight in kg17
Length of supply lead in m1.50
Standard plug fitted
Total rated load in kW0.12
Voltage in V230
Fuse rating in A10
Frequency in Hz50
Number of phases1

INSTALLATION NOTES

Extraction ducting connection at top
Extraction ducting connection on side
Extraction ducting connection at top, rear, and si
Diameter of extraction ducting connection in mm150
Combination with WiFi-enabled Miele hobrequired

ACCESSORIES INCLUDED

Non-return flap
Adapter to reduce ducting diameter from 150 mm to 125 mm Ø

EAN

4002516003465

Discover the Miele DA2808 90cm Built In Ceiling Extractor Hood in Brilliant White on KDH Electrical. Brilliant White Finish Miele Ceiling Extractor Hood – Duct Out or Recirculation (sold separately), Remote control operation (not included), Run-On function, Filter Indicator & Noise Rating of just 57dB(A) with Energy Rating A+. Stainless Steel (10-ply) Grease Filter – Can be cleaned in Dishwasher. Powerful – 725 m3/h on booster setting. Energy Efficient – LED Lighting. Miele CleanCover – Easy cleaning & Protects electrical components + motor. Miele@Home – Make your life smart; connect up all your Miele appliances using your smart devices.



STAINLESS STEEL GREASE FILTERS (10-LAYER) – Easy to use and effective against grease

Miele cooker hoods are equipped with 10-ply stainless-steel grease filter(s) for excellent grease removal. Built-in fall protection allows you to handle them safely and protects your hob from damage. The top layer and filter frame are made of high-quality stainless steel so that no visible discolouration occurs from being cleaned in the dishwasher and they retain their stunning appearance.



MIELE CLEANCOVER – Convenience and safety in detail

Located behind the grease filters is the Miele CleanCover: Instead of sharp metal edges and electrical components you will find only a sealed, smooth surface. It is particularly easy to clean and protects you from coming in contact with cables and motor components. Miele attention to detail – for your convenience and safety.



SAFETY SWITCH-OFF – Always on the safe side

The cooker hood will switch off automatically after 10 hours. This ensures maximum safety even in the event of operating errors.



ECO MOTOR – The heart of every cooker hood

The heart and soul of every cooker hood is the motor. Some Miele cooker hoods feature ECO motors which work up to 50 % more economically than conventional motors. They are also very quiet but still as powerful as the motors in other Miele cooker hoods.



CON@CTIVITY (Miele@Home) – Automatic operation for intelligent fan control

Thanks to the Con@ctivity automatic function, the cooker hood can communicate with the hob below: the settings selected on the hob are transmitted to the controls on the cooker hood. Your Miele cooker hood then uses this data to automatically select the correct fan setting, ensuring the optimum room climate at all times. Communication is established between the cooker hood and hob via WiFi.



RUN-ON FUNCTION – Automatic fan run-on

The automatic fan run-on ensures the full extraction of steam and odours still in the air after cooking. The cooker hood can be set to switch off automatically after 5 or 15 minutes.



FILTER INDICATOR – Countdown time conveniently in view

If the grease or active charcoal filter of your Miele cooker hood is saturated, it is indicated by a lit-up red LED. Your filter should then be cleaned or replaced as soon as possible. You can individually adjust the factory-set service life of the filters: The grease filter saturation indicator can be programmed for 20, 30, 40 or 50 hours, the indicator for active charcoal filter replacement for 120, 180 or 240 hours.



EDGE EXTRACTION – Decorative panels instead of metal grease filters

In cooker hoods with edge extraction panels, the commercial-looking metal grease filters are hidden behind a decorative cover. The cooking vapours are drawn in at the outer edges.

Additional information

Weight17 kg
DimensionsH: 34.2 x W: 88 x D: 50
Brand

Miele

Colour

White

Energy Rating

A+

Extraction Type

Recirculation or Duct Out

Noise Level (dB)

57

Programmes

4

Smart Appliance

Yes

SKUDA2808
GTIN4002516003465
Miele DA2808 90cm Built In Extractor Hood
2 Year Warranty
Discontinued Product
