SPECIFICATION
Product Family
Hob
Dimensions
80 cm
Type
Induction with integrated hood
Extraction
Expulsion
Built-in
Ultra-low profile or Fully Flushed
Power supply
Electric
Electronic control
Yes
EAN code
8017709298685
AESTHETICS
Colour
Black
Finishing
Glass
Aesthetics
Universal
Material
Glass
Glass Type
Ceramic
Type of control setting
Multi Slider
Control knobs position
Front
Slider
Yes
Glass edge
Straight edge
Pan stands
Cast iron
Serigraphy colour
Grey
PROGRAMS / FUNCTIONS
Total no. of cook zones
2
No. of induction cook zones
4
Time-setting options
Automatic switch-off
No. of cooking zones with booster
4
No. of Flexible zones
2
Main on/off switch
Yes
Power levels
9
Auto-vent 2.0
Yes
OPTIONS
Standard cut out
482-483×765-766 mm
Multizone Option
Yes
Flexible Zone Type
MultiZone
End cooking timer
4
Pause option
Yes
Minute minder
1
End of cooking acoustic alarm
Yes
Residual time indicator
Yes
Control Lock / Child Safety
Yes
Keep warm automatic function
Yes
Quick start
Yes
Simmering Function
Yes
Melting/Low temperature cooking function
Yes
Rapid level selection
Yes
COOKING ZONES
1st zone position
Left
2nd zone position
Right
1st zone type
Induction – Multizone
2nd zone type
Induction – multizone
1st zone dimensions
23.0×21.0 cm
2nd zone dimensions
23.0×21.0 cm
3rd zone dimensions
23.0×21.0 cm
4th zone dimensions
23.0×21.0 cm
Left Multizone dimension
46.0×21.0 cm
Right Multizone dimension
46.0×21.0 cm
1st zone power
2.10 kW
2nd zone power
2.10 kW
3rd zone power
2.10 kW
4th zone power
2.10 kW
1st zone booster power
3.70 kW
2nd zone booster power
3.70 kW
3rd zone booster power
3.70 kW
4th zone booster power
3.70 kW
Booster power left Multizone
3.70 kW
Booster power right Multizone
3.70 kW
TECHNICAL FEATURES
Automatic setting according to pan dimension
Yes
Permanent Automatic Pot Detection with indication of the relative control
Yes
Automatic pan detection
Yes
Automatic switch off when overflow
Yes
Residual heat indicator
Yes
Protection against accidental start up
Yes
PERFORMANCE / ENERGY LABEL
Annual Efficiency Consumption (AEChood)
25 KWh/year
Hob energy consumption
194.0 Wh/Kg
1st zone energy consumption
194.0 Wh/Kg
2nd zone energy consumption
194.0 Wh/Kg
ELECTRICAL CONNECTION
Nominal power (W)
7545 W
Voltage (V)
220-240 V
Voltage 2 (V)
380-415 V
Frequency (Hz)
50/60 Hz
Type of electric cable
Universal
Power supply cable length
120 cm
CONTROLS (HOOD)
Hood control setting
Touch Capacitive
Led colour
White
Display
Yes
PROGRAMS / FUNCTIONS (HOOD)
No. of speeds
8
Intensive speed
2
Other functions
AUTOVENT
TECHNICAL FEATURES (HOOD)
Free outlet maximum capacity
750 m³/h
Motor power
220 W
No. of filters
1
Anti-grease filters
Aluminium
Filter replacement indicator
Yes
SPEED 1
Extraction rate IEC 61591
245 m³/h
Noise level IEC 60704-2-13
51 dB(A)
Power
35 W
SPEED 2
Extraction rate IEC 61591
285 m³/h
Noise level IEC 60704-2-13
55 dB(A)
Power
45 W
SPEED 3
Extraction rate IEC 61591
350 m³/h
Noise level IEC 60704-2-13
57 dB(A)
Power
60 W
SPEED 4
Extraction rate IEC 61591
380 m³/h
Noise level IEC 60704-2-13
59 dB(A)
Power
75 W
SPEED 5
Extraction rate IEC 61591
410 m³/h
Noise level IEC 60704-2-13
62 dB(A)
Pressure
535 Pa
Power
85 W
SPEED 6
Extraction rate IEC 61591
445 m³/h
Noise level IEC 60704-2-13
63 dB(A)
Pressure
540 Pa
Power
105 W
SPEED 7
Extraction rate IEC 61591
475 m³/h
Noise level IEC 60704-2-13
64 dB(A)
Pressure
545 Pa
Power
115 W
SPEED 8
Extraction rate IEC 61591
505 m³/h
Noise level IEC 60704-2-13
65 dB(A)
Pressure
550 Pa
Power
125 W
INTENSIVE SPEED
Extraction rate (IEC 61591)
550 m³/h
Noise level IEC 60704-2-13
66 dB(A)
Power
140 W
INTENSIVE SPEED 2
Extraction rate IEC 61591
700 m³/h
Noise level IEC 60704-2-13
72 dB(A)
Pressure
560 Pa
Power
220 W
PERFORMANCE / ENERGY LABEL (HOOD)
Energy efficiency class ( EEC)
A+++
Fluid Dynamic Efficiency class (FDEC)
A
Grease Filtering Efficiency Class (GFEC)
B
Fluid Dynamic Efficiency (FDE)
40.30
Lighting Efficiency (LE)
0.0 lux/W
Grease Filtering Efficiency (GFE)
85.1 %
Air flow at minumum speed (Qmin)
245 m³/h
AIR FLOW AT MAXIMUM SPEED (QMAX)
505 m³/h
Air flow at boost speed (Qboost)
700 m³/h
Airbourne acouistical A-weighted sound Power Emission at minimum speed (SPEmin)
51 dB(A)
Airborne acoustical A-weighted sound Power Emission at maximum speed (SPEmax)
65 dB(A)
Airbourne acoustical A-weighted sound power emission at boost speed (SPEboost)
72 dB(A)
Power Consumption in Off mode (Po)
0.49 W
Time increase factor (F)
0.5
Energy Efficiency Index per first cavity
27.5
Measured air flow rate at best efficiency point (Qbep)
359 m³/h
Measured air pressure at best efficiency point (Qbep)
549 Pa
Measured electric power input at best efficiency point (Wbep)
136 W
Sound power level at highest setting (Lwa)
65 dB(A)
ELECTRICAL CONNECTIONS (HOOD)
Frequenza cappa
50-60 Hz
LOGISTIC INFORMATION
Dimensions of the product (mm)
210x830x520
Depth (mm)
520 mm
Width (mm)
830 mm
Product Height (mm)
210 mm
Net weight (kg)
19.000 kg
Gross weight (kg)
26.000 kg
Discover the Smeg HOBD682D1 80cm 4 Zone Universal Vented Induction Hob in Black Glass on KDH Electrical. A+++ Energy Efficiency Rating – Low energy consumption. MultiZone – Two independent cooking zones or combined into a single zone. Ultra Low Profile – Very sleek height of 1mm when installed or can be flush mounted.
Multizone Operation
Smeg’s MultiZone heating zone can be used as two independent cooking zones or combined into a single zone.
Each zone automatically adapts to the size and position of the dishes and is heated only where the pans locate, providing better heat distribution.
POWERFUL, QUIET OPERATION
All of Hobd’s energy is derived from its powerful motor: boasting effective performance and low energy consumption rated efficient A+++. Compact in size, it is equipped with a special AquaProof Engine plus two liquid collectors, ensuring the appliance is simple to clean whilst containing accidental spillages.
Combining design and technology
Smeg’s ‘Hobd’ hood in hob is composed of a single piece of premium glass. Protected by an elegant cast iron grill, the HOBD’s extraction system allows the entire surface to appear completely seamless – where pans can be moved freely between positions.
Fast operation
Induction allows for precise temperature control when doing intricate cooking, or simmering for example. Heat is only generated when the pan comes into direct contact of the specific cooking zone, ensuring safety in the presence of children. This helps optimise power consumption, only using the energy needed to heat the pan itself.
Induction is faster than gas cooking taking only a little over a minute to boil a pint of water. Another benefit is that any splashes will not burn onto the hob top and are easily wiped clean making it safe and user friendly.
AUTO-VENT
Smeg’s innovative Auto-Vent system connects the hob to the hood and controls the extraction fan speed automatically to suit the cooking temperature and power settings on the hob itself.
| Weight | 19 kg |
|---|---|
| Dimensions | H: 21 x W: 83 x D: 52 |
| Brand | Smeg |
| Colour | Black |
| Cooking Zones | 4 |
| Energy Rating | A+++ |
| Extraction Type | Duct Out |
| Noise Level (dB) | 72 |
| Programmes | 4 |
| Smart Appliance | Yes |
| SKU | HOBD682D1 |
| GTIN | 8017709298685 |
